Automatic spraying line of glass bottles

Share to:
    Payment Type: T/T,Western Union
    Incoterm: FOB,CFR,CIF
    Min. Order: 1 Set/Sets
    Delivery Time: 40 Days

Basic Info

Model No.: HYJ-149

Material: Glass

Usage: Food

Sealing Type: Screw Cap

Shape: High Bottle

Plastic Type: ABS

Type: Wine Bottle Production Line

Color: Red,Bule,Gold,tec

Spray Line: 240m

Additional Info

Packaging: wood box

Productivity: 40

Brand: HENGYIJIA

Transportation: Ocean

Place of Origin: Shenzhen

Supply Ability: 6

Certificate: ISO,CE

Port: Shenzhen

Product Description

Automatic production line of glass bottles

Consists of three major components - automatic spraying, online drying and high temperature baking system, glass bottle spray production using chain drive. After cleaning the glass bottle by the upper part, in the spray room single row automatic spraying, into the drying room after drying, off the assembly line, into the turnover box, into the high temperature baking furnace sintering, inspection package after storage. According to the production situation, after firing the imitation ceramic bottles, can be decals and baked flowers.

characteristic:

Spraying system using a fixed gun to form a multi-nozzle large chance of automatic spraying method, the glass bottle through the rotation system to produce rotation, to ensure that the bottle even by the coating, to ensure quality.

Process flow

Glass bottle → cleaning → drying → bottle → automatic spraying → hot air drying → bottle → turn → into the plane high temperature baking → the next test → (decals → turnover box → into the kiln flowers → kiln test) → the next package

The production line with electrostatic dust, flame treatment, automatic spraying, infrared drying, UV light curing process to take the whole process of automation, combined with the evaporation plating, can cause good coating performance.

Process flow

On-line → flame treatment → automatic electrostatic dust removal → spray primer → primer drying → lower → vacuum coating → → → automatic electrostatic precipitator → spray paint → UV light curing → cooling → the next package

painted wine glassesAutomatic production line of glass bottles
